PTA High Pressure Balloon Catheter

DKaptain™

PTA High Pressure Balloon Catheter

510(k) K214009

Indicated for Percutaneous Transluminal Angioplasty (PTA) in the peripheral vasculature, including iliac, femoral, tibial, peroneal, subclavian, and renal arteries and for the treatment of obstructive lesions of native or synthetic arteriovenous dialysis fistulae. This catheter is not for use in the coronary vasculature.

Technical Specifications



Catheter Type OTW
Guidewire Compatibility 0.035”
Compliance Type Non-compliant
Balloon Diameters 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm
Balloon Lengths 20, 30, 40, 60, 80, 100, 120, 150 mm
Catheter Lengths 50, 75, 130 cm
Sheath Compatibility 5F (3.0, 4.0 mm)

6F (5.0, 6.0, 7.0 mm)

7F (8.0, 9.0, 10.0 mm)

8F (12.0 mm)
Nominal Pressure (NOM) 8, 10 atm
Rated Burst Pressure (RBP) 14, 18, 22, 26 atm
Balloon Material Nylon (3.0 – 4.0 mm)

Nylon + Pebax (5.0 – 12.0 mm)



Catheter Length (50cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √



Catheter Length (75cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √



Catheter Length (130cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √

DKaptain™ - PTA High Pressure Balloon Dilatation Catheter

Technical Specifications



Catheter Type OTW
Guidewire Compatibility 0.035”
Compliance Type Non-compliant
Balloon Diameters 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm
Balloon Lengths 20, 30, 40, 60, 80, 100, 120, 150 mm
Catheter Lengths 50, 75, 130 cm
Sheath Compatibility 5F (3.0, 4.0 mm)

6F (5.0, 6.0, 7.0 mm)

7F (8.0, 9.0, 10.0 mm)

8F (12.0 mm)
Nominal Pressure (NOM) 8, 10 atm
Rated Burst Pressure (RBP) 14, 18, 22, 26 atm
Balloon Material Nylon (3.0 – 4.0 mm)

Nylon + Pebax (5.0 – 12.0 mm)



DKaptain™ - PTA High Pressure Balloon Dilatation Catheter
