PTA High Pressure Balloon Catheter Kit

DKaptain™

PTA High Pressure Balloon Catheter Kit

NMPA 20213030881

Indicated for Percutaneous Transluminal Angioplasty (PTA) of the peripheral vasculature, including the iliac, femoral, popliteal, tibial, peroneal, subclavian, and renal arteries and for the treatment of obstructive lesions of native or synthetic arteriovenous dialysis fistulae. The catheter is indicated for the treatment of biliary strictures with balloon lengths up to 120 mm.

Technical Specifications



Catheter Type OTW
Guidewire Compatibility 0.035”
Compliance Type Non-compliant
Balloon Diameters 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm
Balloon Lengths 20, 30, 40, 60, 80, 100, 120, 150 mm
Catheter Lengths 50, 75, 130 cm
Sheath Compatibility 5F (3.0, 4.0 mm)

6F (5.0, 6.0, 7.0 mm)

7F (8.0, 9.0, 10.0 mm)

8F (12.0 mm)
Nominal Pressure (NOM) 8, 10 atm
Rated Burst Pressure (RBP) 14, 18, 22, 26 atm
Balloon Material Nylon (3.0 – 4.0 mm)

Nylon + Pebax (5.0 – 12.0 mm)



Catheter Length (50cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √



Catheter Length (75cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √



Catheter Length (130cm) Balloon Length (mm)
Balloon Diameter (mm) 20mm 30mm 40mm 60mm 80mm 100mm 120mm 150mm
3.0mm √ √ √ √ √ √ √ √
4.0mm √ √ √ √ √ √ √ √
5.0mm √ √ √ √ √ √ √ √
6.0mm √ √ √ √ √ √ √ √
7.0mm √ √ √ √ √ √ √ √
8.0mm √ √ √ √ √ √ √ √
9.0mm √ √ √ √ √
10.0mm √ √ √ √ √
12.0mm √ √ √ √ √

Please contact DK Medtech team for more information.

Technical Specifications



Catheter Type OTW
Guidewire Compatibility 0.035”
Compliance Type Non-compliant
Balloon Diameters 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm
Balloon Lengths 20, 30, 40, 60, 80, 100, 120, 150 mm
Catheter Lengths 50, 75, 130 cm
Sheath Compatibility 5F (3.0, 4.0 mm)

6F (5.0, 6.0, 7.0 mm)

7F (8.0, 9.0, 10.0 mm)

8F (12.0 mm)
Nominal Pressure (NOM) 8, 10 atm
Rated Burst Pressure (RBP) 14, 18, 22, 26 atm
Balloon Material Nylon (3.0 – 4.0 mm)

Nylon + Pebax (5.0 – 12.0 mm)



Please contact DK Medtech team for more information.
