Indicated for the endovascular dilatation treatment of stenosis or occlusion in peripheral arteries and veins, such as renal artery, femoral artery, iliac artery, subclavian artery, popliteal artery, carotid artery and tibial artery, but excluding intracranial arteries and veins.
It is also indicated for use in the treatment of stenotic or occluded lesions of autologous or synthetic arteriovenous dialysis fistulae.
Technical Specifications
| Catheter Type | OTW |
| Guidewire Compatibility | 0.018” & 0.035” |
| Compliance Type | Non-compliant |
| Balloon Diameters | 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm |
| Balloon Lengths | 20, 40, 60, 80, 100, 120, 150 mm |
| Catheter Lengths | 50, 90, 130 cm |
| Sheath Compatibility | PTA18:
4F (2.0, 2.5, 3.0, 4.0 mm) 5F (5.0, 6.0, 7.0, 8.0 mm) PTA35: 5F (4.0, 5.0 mm) 6F (6.0, 7.0 mm) 7F (8.0, 9.0, 10.0 mm) 8F (12.0 mm) |
| Nominal Pressure (NOM) | 6, 8, 10 atm |
| Rated Burst Pressure (RBP) | 10, 12, 14, 20, 24 atm |
| Balloon Material | Nylon |
| 0.018″ | Balloon Length (mm) | |||||
| Balloon Diameter (mm) | 20mm | 40mm | 60mm | 80mm | 120mm | 150mm |
| 2.0mm | √ | √ | √ | √ | √ | √ |
| 2.5mm | √ | √ | √ | √ | √ | √ |
| 3.0mm | √ | √ | √ | √ | √ | √ |
| 4.0mm | √ | √ | √ | √ | √ | √ |
| 5.0mm | √ | √ | √ | √ | √ | √ |
| 6.0mm | √ | √ | √ | √ | √ | √ |
| 7.0mm | √ | √ | √ | √ | √ | √ |
| 8.0mm | √ | √ | √ | √ | √ | √ |
| 0.035″ | Balloon Length (mm) | ||||||
| Balloon Diameter (mm) | 20mm | 40mm | 60mm | 80mm | 100mm | 120mm | 150mm |
| 4.0mm | √ | √ | √ | √ | √ | √ | √ |
| 5.0mm | √ | √ | √ | √ | √ | √ | √ |
| 6.0mm | √ | √ | √ | √ | √ | √ | √ |
| 7.0mm | √ | √ | √ | √ | √ | √ | √ |
| 8.0mm | √ | √ | √ | √ | √ | √ | √ |
| 9.0mm | √ | √ | √ | √ | |||
| 10.0mm | √ | √ | √ | √ | |||
| 12.0mm | √ | √ | √ | √ | |||
Technical Specifications
| Catheter Type | OTW |
| Guidewire Compatibility | 0.018” & 0.035” |
| Compliance Type | Non-compliant |
| Balloon Diameters | 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0, 12.0 mm |
| Balloon Lengths | 20, 40, 60, 80, 100, 120, 150 mm |
| Catheter Lengths | 50, 90, 130 cm |
| Sheath Compatibility | PTA18:
4F (2.0, 2.5, 3.0, 4.0 mm) 5F (5.0, 6.0, 7.0, 8.0 mm) PTA35: 5F (4.0, 5.0 mm) 6F (6.0, 7.0 mm) 7F (8.0, 9.0, 10.0 mm) 8F (12.0 mm) |
| Nominal Pressure (NOM) | 6, 8, 10 atm |
| Rated Burst Pressure (RBP) | 10, 12, 14, 20, 24 atm |
| Balloon Material | Nylon |
